Saffire LX-P Exit Trim Series Templates and Instructions(Compatible with Community) |
Templates
Click on the template ID of the template you wish to download.
| Template ID | Description | Rev | Last Update |
ARROW | |||
| DT-516418-7A |
Saffire LX-P |
4 | 05/2024 |
| IP-516418-7A |
Saffire LX-P
|
2 | 05/2024 |
| DT-516418-4A |
Saffire LX-P Arrow S3888/S3788 Drilling Template |
4 | 05/2024 |
| IP-516418-4A |
Saffire LX-P Arrow S3888/S3788 Door Prep |
2 | 05/2024 |
CORBIN RUSSWIN | |||
| DT-516418-5A |
Saffire LX-P Corbin Russwin ED5200/ED5400 Drilling Template |
4 | 05/2024 |
| IP-516418-5A |
Saffire LX-P Corbin Russwin ED5200/ED5400 Drilling Template |
2 | 05/2024 |
DETEX | |||
| DT-516418-1A |
|
3 | 05/2024 |
| IP-516418-1A |
|
2 | 05/2024 |
| DT-516418-11A |
|
4 | 05/2024 |
| IP-516418-11A |
Saffire LX-P Detex V40 Drilling Template |
2 | 05/2024 |
DORMAKABA | |||
| DT-516418-16A |
Saffire LX-P dormakaba 8300/8400 Drilling Template |
4 | 05/2024 |
| IP-516418-16A |
Saffire LX-P dormakaba 8300/8400 Drilling Template |
3 | 05/2024 |
| DT-516418-9A |
Saffire LX-P dormakaba 9100/F9100/9100FL/F9100FL Drilling Template |
4 | 05/2024 |
| IP-516418-9A |
Saffire LX-P dormakaba 9100/F9100/9100FL/F9100FL Door Prep |
2 | 05/2024 |
| DT-516418-2A |
Saffire LX-P dormakaba 9300/F9300/9400/F9400 Drilling Template |
4 | 05/2024 |
| IP-516418-2A |
Saffire LX-P dormakaba 9300/F9300/9400/F9400 Door Prep |
2 | 05/2024 |
| DT-516418-14A |
Saffire LX-P dormakaba 9500/F9500 Drilling Template |
4 | 05/2024 |
| IP-516418-14A |
Saffire LX-P dormakaba 9500/F9500 Drilling Template |
2 | 05/2024 |
HAGAR | |||
| DT-516418-6A |
Saffire LX-P Hagar 4500 Drilling Template |
4 | 05/2024 |
| IP-516418-6A |
Saffire LX-P Hagar 4500 Drilling Template |
2 | 05/2024 |
MONARCH | |||
| DT-516418-13A |
Saffire LX-P Monarch 18-R Drilling Template |
4 | 05/2024 |
| IP-516418-13A |
Saffire LX-P Monarch 18-R Door Prep |
2 | 05/2024 |
PRECISION | |||
| DT-516418-1A |
Saffire LX-P Precision 21, FL21, 22, FL22 Drilling Template |
4 | 05/2024 |
| IP-516418-1A |
|
2 | 05/2024 |
| DT-516418-17A |
Saffire LX-P Precision 5100, 5200 Drilling Template |
3 | 05/2024 |
| IP-516418-17A |
Saffire LX-P Precision 5100, 5200 Drilling Template |
3 | 05/2024 |
SARGENT | |||
| DT-516418-12A |
Saffire LX-P Sargent 8710F Drilling Template |
4 | 05/2024 |
| IP-516418-12A |
Saffire LX-P Sargent 8710F Door Prep |
2 | 05/2024 |
SURFACE MOUNT | |||
| DT-516418-15A |
Saffire LX-P Surface Mount Drilling Template |
4 | 05/2024 |
| IP-516418-15A |
Saffire LX-P Surface Mount Drilling Template |
2 | 05/2024 |
VON DUPRIN | |||
| DT-516418-17A |
Saffire LX-P Von Duprin 22 Drilling Template |
4 | 05/2024 |
| IP-516418-17A |
Saffire LX-P Von Duprin 22 Door Prep |
3 | 05/2024 |
| DT-516418-1A |
Saffire LX-P Von Duprin 98/99/9827/9927 Drilling Template |
4 | 05/2024 |
| IP-516418-1A |
|
2 | 05/2024 |
| DT-516418-10A |
Saffire LX-P Von Duprin 9847/9947L Drilling Template |
4 | 05/2024 |
| IP-516418-10A |
Saffire LX-P Von Duprin 9847/9947L Drilling Template |
2 | 05/2024 |
| DT-516418-3A |
Saffire LX-P Von Duprin 9875/9975 Drilling Template |
4 | 05/2024 |
| IP-516418-3A |
Saffire LX-P Von Duprin 9875/9975 Door Prep |
2 | 05/2024 |
| YALE | |||
|
|
Saffire LX-P Yale 7100/7170 Drilling Template |
4 | 05/2024 |
| IP-516418-5A |
Saffire LX-P Yale 7100/7170 Door Prep |
2 | 05/2024 |
| DT-516418-8A |
Saffire LX-P Yale 7160 Drilling Template |
4 | 05/2024 |
| IP-516418-8A |
Saffire LX-P Yale 7160 Drilling Template |
2 | 05/2024 |
Instructions
| Document ID | Description | Rev | Last Updated |
| PK3713 |
Saffire LX-P Exit Device Operators Installation Instructions |
2 | 03/2024 |
How to Videos
Unboxing and Installing the Saffire LX-P
Care and Maintenance
Important Information
Before using any cleaning or disinfecting product, please take the following steps:
• Only use products that are recommended for the intended surfaces - particularly on plastic surfaces, especially when using alcohol-based cleaning agents
• Always visit the website of the cleaning product manufacturer for a list of specific properties or instruction guidelines
• Pay special attention to plastic surfaces with a gloss finish as these may be more susceptible to scratching or tarnishing
• We strongly recommend first testing any new product on a small surface and waiting for a period of 4 hours to ensure there is no detrimental effect
Extreme Conditions
For locks with Ocean Front finish, we also recommend regular cleaning and waxing.
• On a weekly basis, remove salt from the lock using a damp cloth. This is for area subject to salt mist.
• We recommend cleaning, polishing and waxing locks using a suitable polisher agent every 6 months and this should be adjusted according to the severity of the environment.
Lock Finish warranty
The standard warranty on the dormakaba lock includes the finish, subject to the conditions mentioned above being met.
Click here to download the Electronic Lock Cleaning Fact Sheet
