EVO LZ-M Mortise Series Templates and Instructions(Not Compatible with Community) |
Templates
Click on the template ID of the template you wish to download.
| Template ID | Description | Rev | Last Update |
| DT-516321A |
|
5 | 05/2024 |
| IP-516321A |
|
2 | 05/2024 |
| DT-515905A |
Saffire EVO LZ-M Mortise ASM 1-1/4" Faceplate 2-3/4" Backset Drilling Template |
7 | 05/2024 |
| IP-515905A |
Saffire EVO LZ-M Mortise ASM 1-1/4" Faceplate 2-3/4" Backset Door Prep |
2 | 05/2024 |
| DT-848764-3A |
Saffire EVO LZ-M Euro Mortise Lock Case 395 Euro Profile Cylinder Drilling Template |
4 | 05/2024 |
| IP-516431-3A |
Saffire EVO LZ-M Euro Mortise Lock Case 395 Euro Profile Cylinder Door Prep |
4 | 05/2024 |
| DT-515431-2A |
Saffire EVO LZ-M Euro Mortise Lock Case 395 Half Euro Knob Profile Cylinder Drilling Template |
4 | 05/2024 |
| IP-516431-2A |
Saffire EVO LZ-M Euro Mortise Lock Case 395 Half Euro Knob Profile Cylinder Door Prep |
4 | 04/2025 |
| DT-515431-1A |
Saffire EVO LZ-M Euro Mortise Lock Case 395 No Euro Profile Cylinder Drilling Template |
4 | 05/2024 |
| IP-516431-1A | Saffire EVO LZ-M Euro Mortise Lock Case 395 No Euro Profile Cylinder Drilling Template |
4 | 05/2024 |
Instructions
| Document ID | Description | Rev | Last Updated |
| PK3704 |
Installation Instructions |
11/2023 | |
| PK519348 | Saffire EVO User Guide | 03/2023 |
How to Videos
How to Rehand the Mortise Locks
Care and Maintenance
Important Information
Before using any cleaning or disinfecting product, please take the following steps:
• Only use products that are recommended for the intended surfaces - particularly on plastic surfaces, especially when using alcohol-based cleaning agents
• Always visit the website of the cleaning product manufacturer for a list of specific properties or instruction guidelines
• Pay special attention to plastic surfaces with a gloss finish as these may be more susceptible to scratching or tarnishing
• We strongly recommend first testing any new product on a small surface and waiting for a period of 4 hours to ensure there is no detrimental effect
Extreme Conditions
For locks with Ocean Front finish, we also recommend regular cleaning and waxing.
• On a weekly basis, remove salt from the lock using a damp cloth. This is for area subject to salt mist.
• We recommend cleaning, polishing and waxing locks using a suitable polisher agent every 6 months and this should be adjusted according to the severity of the environment.
Lock Finish warranty
The standard warranty on the dormakaba lock includes the finish, subject to the conditions mentioned above being met.
Click here to download the Electronic Lock Cleaning Fact Sheet
